24 Pin Centronic PCB Right Angle Female Connector Certified UL
-
-
صورة كبيرة :
24 Pin Centronic PCB Right Angle Female Connector Certified UL
|
تفاصيل المنتج:
| Place of Origin: |
China |
| اسم العلامة التجارية: |
FUYCONN |
| إصدار الشهادات: |
UL 94-V0, ROHS-certified, ISO 9001:2008, ISO 14001:2004 |
| Model Number: |
FUY57058A-24P |
شروط الدفع والشحن:
| Minimum Order Quantity: |
1000pcs |
| الأسعار: |
Negotiable |
| Packaging Details: |
Vacuum Tray + Carton |
| Delivery Time: |
7-10 days |
| Payment Terms: |
T/T or Paypal |
| Supply Ability: |
1 million/ month |
|
مفصلة وصف المنتج
FUY57058A 24 Way 90 Degree PCB Mount Centronics Female Right Angle Connector 2.16 mm pitch
Detail Description:
Product Category: Centronic connector
Product Line: Champ Connector
Type: Right Angle PCB Connector
Number of Terminal: 24 pin
PCB Mount Style:Right Angle
Connector Style:Receptacle
Gender: Female
Insulator Color: Black or Blue
Insulator Material: PBT
Contact pin Material: Phosphor Bronze
Shield Plating: Nickel
Centerline = 2.16mm [0.085in]
Mating Lock: Z Bracket Board lock
Mounting Option: Reversed, Round Head Screws
Application: PCB Board
Advantage:
1,ROHS compliant, UL-approved
2,High quality, Competitive price
3,Quick delivery time
4,Free sample available in 2 days
Common Features
| Designed for Cable-to-cable and cable-to-PC Board applications |
| Board Application |
| Available in Plug & Socket styles |
| Terminal Option with various types |
| Connector and hood sold as complete assembly |
| Available in low profile hood style |
| Metal shell provides grounding and shielding capability |
| Mates with industry compatible connector |
Product Features
| Product Type: |
Centronics PCB Mounting Connector |
| Product Line: |
Champ Connector |
| Gender: |
Female |
| Connector Style: |
Receptacle |
| Certerline : |
2.16mm(0.85in) |
| Number of Position: |
24 pin |
| Contact Plating: |
Gold Plating (1U", 3U", 5U" ,10U", 15U", 30U") |
| Terminals Type |
Right Angle Terminals |
| Insulator Color: |
Black or Blue |
| Shielded: |
Yes |
| Orientation: |
R/A |
| Mating connector lock: |
Board Lock |
Materials
| Contact Material: |
Phosphor Bronze |
| Insulator: |
PPT (UL 94-V0) |
| Shell |
Nickel Plated Steel |
Electrical Character
| Current Rating: |
5Amp |
| Withstanding Voltage: |
AC 1000v r.m.s |
| Insulation Resistance: |
1000 Megohms Minimum at DC 500V |
| Contact Resistance: |
25M∩ Max Mated |
| Operation Temperature: |
-55°C to +105°C |
Application
| 1, VDSL Teleccom Equipment |
| 2, Computer Peripherals |
| 3, Communication Equipment |
| 4, PCB Board |
| 5, Cable to Panel |
| 6, Cable to cable |
| 7,Computer terminal |
| 8,Telemetering |
| 9,Test Equipment |
| 10, Printer |
